Video Recorder 630/650 Series Operating instructions | en 45
Bosch Security Systems Installation and Operation manual F.01U.169.663 | v2.0 | 2012.02
5.8 Export
The export menu is accessed by pressing the Export key on the Front Panel or from the
System Control Bar. It allows writing segments of recorded video and audio to a USB storage
device or recordable DVD.
Figure 5.9 Export menu
1. Choose to record to either USB or CD/DVD from the Target Device selection box.
2. Select the Channel to archive ( ... for all channels).
3. Fill in a Start time and End time for the video segments to archive.
4. Click Export to create the archive.
– To open the CD/DVD burner, click the Eject button.
– To erase a USB drive after it has been inserted, click the Format button.
If the total size of the video segments is greater than the memory device’s free space,
then only the first segments that fit are archived.
5. Click File to save ‘Export history log file’ to USB.
