84 en | Archive Player Video Recorder 630/650 Series
F.01U.169.663 | v2.0 | 2012.02 Installation and Operation manual Bosch Security Systems
8.4 Viewing Images
8.4.1 Assigning Cameos
A cameo is a single camera picture in a multiscreen display.
To assign a camera to a cameo:
1. Click on a Cameo;
– the selected cameo has a yellow border.
2. Double-click a camera from the list.
To undo a cameo assignment:
– Click the close button on the cameo.
If audio is present on the channel when a cameo is selected, it will be played.
8.5 Using the playback controls
Figure 8.3 Archive Player - playback controls
Play
Click the Play button to play recorded video forward in the playback window:
– The playback speed depends on the setting of the speed slider.
– Some frames may be dropped depending on the PC resources, selected playback
speed, or insufficient network bandwidth.
Play Reverse
Click the Play reverse button to play recorded video in reverse in the playback window:
– The playback speed depends on the setting of the speed slider.
– Some frames will be dropped in Play Reverse as a result of the compression
process. Additional frames may be dropped as a result of the selected playback
speed or insufficient network bandwidth.
Playback Speed
The slider controls the speed of the continuous forward and reverse play.
Still
Click the Still button to pause playback;
– The last image is shown as a still in the playback window.
Step forward
The step function is only enabled in the still mode.
1. Click the Step forward button to move the image forward one frame.
2. Hold it down to continue stepping at a maximum rate of 3 images per second.
Step backward
The step function is only enabled in the still mode.
1. Click Step backward to move the image back one frame.
2. Hold it down to continue stepping at a maximum rate of 3 images per second.
