1.4.2 Symbols and representations
CAUTION
Bodily harm or damage to equipment may result.
NOTE
Damage to equipment may result.
If this information is not observed, the operating procedure may be impaired.
Table 1–2: Symbols and representations used in the documentation
Symbol Explanation
Prerequisite
Ensure that the stipulated prerequisite is met before proceeding to the next step.
Step
This symbol indicates an individual step.
1.
2.
3.
Sequence of steps
Take the steps specified while following the order specified.
Result
This symbol indicates the result of a step.
Example Examples are in a gray field and illustrate the previously stated information.
A tip provides additional information that is not decisive for working with the tightening system, but
is important and useful.
Blue text References to other sections are shown in blue. Click the reference in the PDF to jump directly to
the referenced target.
Bold text Special text is shown in bold. This includes operating elements, screen displays, or important text
passages.
<n> Angle brackets indicate a variable value that can be replaced with a specific value in the concrete
case.
