238/263 Bosch Rexroth AG | Tightening Technology 3 608 870 A47
Nexo cordless Wi-Fi nutrunner | 3 608 870 A47/2017-
9.8.13 ID assignment
Settings ID assignment
The ASCII code can be linked to a tightening program or a job, i.e. when the code is read, the respective
tightening program or the job starts. Specify the required settings in the ID assignment table.
Configure the respective operating mode in the Mode tab. Go to ID code step under Target selection
ID input to specify that a tightening program or job is to be selected using the ID assignment table.
9.8.14 Scanner
Settings Scanner
Use this menu item to define the configuration of the scanner integrated into the hand-held nutrunner.
Settings Scanner Scanner configuration
Table 9–89: ID assignment tab
Element Description
ID assignment table Use this menu item to change the ID assignment table.
–ASCII
Enter the ASCII characters of the code to select a tightening program or
job.
–Program
Enable the checkbox to activate the tightening program.
–Job
Enable the checkbox to activate the job.
–No.
Enter the number of the tightening program or job. Integer values between
0 and 255 are valid characters.
– Comments
Enter a comment.
Add Adds a new entry in the assignment table.
Remove Deletes an entry from the assignment table.
Save Click Save to save the edited data.
Discard Click Discard to discard the edited data.
Import Opens the Import dialog. Select the file to be imported.
Export Exports the current settings to the download area.
Restore defaults All settings in this tab are reset to the factory setting.
Table 9–90: Scanner tab - scanner configuration
Element Description
Active Enable the checkbox to activate the barcode scanner.
Barcodes For an overview of the supported barcodes, see table 9–91.
There are several options for the length of the corresponding barcode:
–L1
Entry of a fix length, e.g. „L1=12“
–
L1;L2
Entry of 2 fixed lengths, e.g. “L1=16;L2=8”
–L1-L2
Entry of a length range, e.g. „L1=3–L2=9“
–Any
No length restriction
Save Click Save to save the edited data.
Discard Click Discard to discard the edited data.
