3 608 870 A47 Tightening Technology | Bosch Rexroth AG 221/263
Nexo cordless Wi-Fi nutrunner | 3 608 870 A47/2017-05
9.8.4.5 VW-XML
Settings  Data  VW-XML
Use this menu item to define the setting for communication with VW-XML of the Nexo cordless Wi-Fi nut-
runner.
Table 9–71: VW-XML index card
Element Description
Active Enable the check box to activate communication with VW-XML.
System data Under System data, the corresponding parameters for
VM-XML tightening results output can be configured.
Tag default setting: empty
– System name <ABZ>
In the “ABZ” tag, 32 characters are available (e.g. wheel assembly).
–Plant <WRK>
In the “WRK” tag, 16 characters are available.
– Production segment <FSG>
In the “FSG” tag, 16 characters are available.
– Production section <FAB>
In the “FAB” tag, 16 characters are available.
– Production unit <FBR>
In the “FBR” tag, 16 characters are available.
– System location <ORT>
In the “ORT” tag, 16 characters are available.
– Assembly side <ABS>
Selection of the connection side:
– Counterclockwise
–Clockwise
– Undefined: empty
In the “ABS” tag, one character is available. “R” for selection of right and
“L” for selection of left.
Interface – TCP/IP port A (control data)
Selection of the desired TCP/IP port for data exchange
with the tightening controller (default setting: 4700)
– Keep alive timeout (A)
Indication of the time in which a message from the master PC is to be re-
ceived. If no message is received within this time at the port, the connec-
tion will be disconnected (default setting: 8 seconds).
Recommendation: Set the keep alive timeout to a higher value than that
of the master PC.
– TCP/IP port B (process data)
Selection of the desired TCP/IP port for process data and event-con-
trolled message exchange (default setting: 4710)
– Keep alive timeout (B)
Indication of the time in which the tightening controller must send a mes-
sage to the master PC. If no message is received within this time at the
port of the master PC, it will disconnect the connection. (Default setting:
6 seconds).
Recommendation: Set the keep alive timeout to a lower value than that of
the master PC.
–ACK timeout
Indication of the time in which a confirmation (acknowledge) is to be re-
ceived. If no confirmation is received within this time at the port, the con-
nection will be disconnected (default setting: 3 seconds).
