Bose L1 II User Manual

11
Figure 2. L1 Model II Line Array Packaging View
L1
®
Model II Line Array (see Figure 2)
Packaging Part List
2
1
3
4
6
7
3
4
1
8
8
5
7
Item
Number
Description Bose
®
Part
Number
Vendor Part
Number
Qty. Note
Carton Kit,
includes items 1 - 6
307721 -
1 Card Sheet 307720 1450-9370+1 2
2 Filler, PE, Type 1 307716 1493-1641+1 1
3 Filler, PE, Type 4 307719 1493-1644+1 2
4 Filler, PE, Type 3 307718 1493-1643+1 2
5 Filler, PE, Type 2 307717 1493-1642+1 1
6 Carton 298675 1437-9702+2-3 1
7 Carry Bag, Line Array Section 044023 SVC-L211+ABAG** 1
8 Poly Bag - 1497-7592+0 2 4
