Bose L1 II User Manual

24
Electrical Part List
Resistors (continued)
Input/Output PCB Assembly
Capacitors
Reference
Designator
Description Vendor Part
Number
Note
C100 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C101 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C102 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C103 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C104 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C105 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C106 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C107 0.01uF, 0603, CC, 50V, 10%, 1x2 150F-103KAC 4
C108 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C109 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104KAC 4
C110 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C111 1000pF, 0603/1608, CC, 50V, 10%, 1X2 150F-102KAC 4
C112 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C113 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C114 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C115 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C116 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C117 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C118 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
C119 100pF, 0603, CC, 50V, 5%, 1X2 150F-101JAC 4
Reference
Designator
Description
V
endor Part
Number
Note
R234 16 OHM, 2512, RMG, 1W, 5% 4728-160J 3, 4
R238 240 OHM, 0603/1608, RMG, 1/16W, 5% 4723-241J 4
R252 9.1K, 0603/1608, RMG, 1/16W, 1% 4723-912A 4
R257 30.9K, 0603/1608, RMG, 1/16W, 1% 4723-3092 4
R261 510 OHM, 1206, RMG, 1/4W, 5% 4725-511J 4
R264 510 OHM, 1206, RMG, 1/4W, 5% 4725-511J 4
R268 510 OHM, 1206, RMG, 1/4W, 5% 4725-511J 4
R271 510 OHM, 1206, RMG, 1/4W, 5% 4725-511J 4
R291 120 OHM, 0603/1608, RMG, 1/16W, 5% 4723-121J 4
R294 120 OHM, 0603/1608, RMG, 1/16W, 5% 4723-121J 4
R298 15K, 0603/1608, RMG, 1/16W, 1% 4723-153
A
4
R299 5.6K, 0603/1608, RMG, 1/16W, 1% 4723-562A 4
R300 7.5K, 0603/1608, RMG, 1/16W, 1% 4723-752A 4
R301 200K, 0603/1608, RMG, 1/16W, 1% 4723-204
A
4
R302 7.5K, 0603/1608, RMG, 1/16W, 1% 4723-752A 4
R305 0 OHM, 1206, RMG, 1/8W, 5% 4721-000J 4
R309 0 OHM, 0603, RMG, 1/16W, 5% 4723-000JR 4
R311 22 OHM, 0603, RMG, 1/16W, 5%, 0603, HK 4723-220J+P-
R
4
R312 22 OHM, 0603, RMG, 1/16W, 5%, 0603, HK 4723-220J+P-R 4
R317 5.1K, 1206, RMG, 1/4W, 5% 4725-512J 4
R318 5.1K, 1206, RMG, 1/4W, 5% 4725-512J 4
R319 5.1K, 1206, RMG, 1/4W, 5% 4725-512J 4
R320 5.1K, 1206, RMG, 1/4W, 5% 4725-512J 4
