Electrical Part List
Integrated Circuits
Power Amplifier PCB Assembly
Miscellaneous
Miscellaneous
AC Primary PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
CON300B WAFER, 3P, P7.92/11.88, STRAIGHT 2101-3097 4
CON300L WAFER, 3P, P7.92/11.88, STRAIGHT 2101-3097 4
E1A SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
E2A SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
E3A SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
FOR AC
INLET
BRACKET, A/C INLET, BSPAPS2 4135-6791 4
J105 INLET, AC, UL/CSA/VDE, 250V, 10A 2113-1144 4
P1 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
P2 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
Reference
Designator
Description Vendor Part
Number
Note
CON300 WAFER, 3P, P7.92/11.88, ST 2101-3097 4
CON301 WAFER, 4P, P3.96, ST, MALE 2101-3053 4
F200 0 OHM, 1206, RMG, 1/8W, 1% 4721-000A 4
J301 6 PIN, WF 2102-060S 4
J302 6 PIN, WF 2102-060S 4
J303 WAFER, 3P, P2.0, ST, MALE 2101-3008 4
MOV VARISTOR, 320V, 10%, SIOV-S10K320 4735-0003 4
N1 THERMISTER, NTC, 100K, 5%, B5, 7620C0104J162,
0805, EPCOS
5202-0019 4
N100 NTC THERMISTER, 5 0HM, 4A, NIOSP005L,
UL/CSA/VDE
5202-0010 4
N101 NTC THERMISTER, 5 0HM, 4A, NIOSP005L,
UL/CSA/VDE
5202-0010 4
N200 THERMISTOR, PTC, 1K, 0805, 90 DEG, EPCOS 5202-0011 4
N201 THERMISTOR, PTC, 1K, 130 DEG, 0805, EPCOS 5202-0021 4
TRAF200 TRANSFORMER, SWITCHING, ETD29 1806-3898 4
Reference
Designator
Description Vendor / Bose
®
Part Number
Note
IC1 HALF BRIDGE DRIVER, LV4970M, SO-16 3132-3051 4
IC2 HALF BRIDGE DRIVER, LV4970M, SO-16 3132-3051 4
IC3 ANALOG 2CH CONT, LV4930M, QUAD44 3132-3061 4
IC4 MC33078DR2G, OP-AMP, SO-8 3132-2711 4
IC200 L6571BD013TR, HALF BRIDGE DRIVER, SO8 291328 4
