Bose L1 II User Manual

23
Electrical Part List
Resistors
Input/Output PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
R98 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R99 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R102 4.99K, 0603, RMG, 1/16W, 1% 4723-4991 4
R104 4.99K, 0603, RMG, 1/16W, 1% 4723-4991 4
R114 5.6K, 0603/1608, RMG, 1/16W, 1% 4723-562A 4
R115 5.6K, 0603/1608, RMG, 1/16W, 1% 4723-562A 4
R116 2.7K, 0603/1608, RMG, 1/16W, 1% 4723-272A 4
R117 4.7K, 0603/1608, RMG, 1/16W, 1% 4723-472A 4
R119 2.7K, 0603/1608, RMG, 1/16W, 1% 4723-272A 4
R120 15K, 0603/1608, RMG, 1/16W, 1% 4723-153A 4
R121 15K, 0603/1608, RMG, 1/16W, 1% 4723-153A 4
R129 5.6K, 0603/1608, RMG, 1/16W, 1% 4723-562A 4
R130 4.7K, 0603/1608, RMG, 1/16W, 1% 4723-472A 4
R131 4.7K, 0603/1608, RMG, 1/16W, 1% 4723-472A 4
R134 0 OHM, 1206, RMG, 1/8W, 5% 4721-000J 4
R139 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R140 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R143 RCFA, 10KX4, 0603, 1/16W, 5% 4703-103J04 4
R144 RCFA, 10KX4, 0603, 1/16W, 5% 4703-103J04 4
R155 RCFA, 10KX4, 0603, 1/16W, 5% 4703-103J04 4
R159 RCFA, 10KX4, 0603, 1/16W, 5% 4703-103J04 4
R167 RCFA, 47 OHMX4, 0603, 1/16W, 5% 4703-470J04 4
R168 RCFA, 47 OHMX4, 0603, 1/16W, 5% 4703-470J04 4
R170 0 OHM, 1206, RMG, 1/8W, 5% 4721-000J 4
R171 0 OHM, 1206, RMG, 1/8W, 5% 4721-000J 4
R174 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340 4
R175 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340 4
R176 634 OHM, 0603, RMG, 1/16W, 1% 4723-6340 4
R177 91 OHM, 0603, RMG, 1/16W, 1% 4723-910A 4
R178 91 OHM, 0603, RMG, 1/16W, 1% 4723-910A 4
R179 1.33K, 0603, RMG, 1/16W, 1% 4723-1331 4
R180 1.33K, 0603, RMG, 1/16W, 1% 4723-1331 4
R181 4.42K, 0603, RMG, 1/16W, 1% 4723-4421 4
R182 4.42K, 0603, RMG, 1/16W, 1% 4723-4421 4
R185 715 OHM, 0603, RMG, 1/16W, 1% 4723-7150 4
R186 715 OHM, 0603, RMG, 1/16W, 1% 4723-7150 4
R187 2.32K, 0603, RMG, 1/16W, 1% 4723-2321 4
R188 2.32K, 0603, RMG, 1/16W, 1% 4723-2321 4
R189 4.99K, 0603, RMG, 1/16W, 1% 4723-4991 4
R190 4.99K, 0603, RMG, 1/16W, 1% 4723-4991 4
R200 0 OHM, 1206, RMG, 1/8W, 5% 4721-000J 4
R201 4.7K, 0603/1608, RMG, 1/16W, 1% 4723-472A 4
R227 0 OHM, 1206, RMG, 1/8W, 5% 4721-000J 4
R229 1M, 0603/1608, RMG, 1/16W, 5% 4723-105J 4
