Bose L1 II User Manual

35
Electrical Part List
Resistors (continued)
Power Amplifier PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
R69 2.7K, 0603/1608, RMG, 1/16W, 1% 4723-272A 4
R70 2.7K, 0603/1608, RMG, 1/16W, 1% 4723-272A 4
R71 2.7K, 0603/1608, RMG, 1/16W, 1% 4723-272A 4
R72 2.7K, 0603/1608, RMG, 1/16W, 1% 4723-272A 4
R77 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R78 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R79 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R80 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R81 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R83 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R87 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R88 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R89 100 OHM, 0603, RMG, 1/16W, 1% 4723-101A 4
R92 2.2K, 0603/1608, RMG, 1/16W, 1% 4723-222A 4
R93 2.2K, 0603/1608, RMG, 1/16W, 1% 4723-222A 4
R94 2.2K, 0603/1608, RMG, 1/16W, 1% 4723-222A 4
R95 2.2K, 0603/1608, RMG, 1/16W, 1% 4723-222A 4
R100 100K, 0805, RMG, 1/10W, 1% 4720-104A 4
R101 100K, 0805, RMG, 1/10W, 1% 4720-104A 4
R102 820K, 0805, RMG, 1/10W, 5% 4720-824J 4
R103 820K, 0805, RMG, 1/10W, 5% 4720-824J 4
R104 820K, 0805, RMG, 1/10W, 5% 4720-824J 4
R105 82K, 0805, RMG, 1/10W, 5% 4720-823J 4
R106 82K, 0805, RMG, 1/10W, 5% 4720-823J 4
R204 22 OHM, 0805, RMG, 1/10W, 5% 4720-220J 4
R205 22 OHM, 0805, RMG, 1/10W, 5% 4720-220J 4
R206 0.12 OHM, 1206, RMG, 1/4W, 5% 4725-R12J 3, 4
R207 0.12 OHM, 1206, RMG, 1/4W, 5% 4725-R12J 3, 4
R208 47K, 0805, RMG, 1/10W, 5% 4720-473J 4
R209 47K, 0805, RMG, 1/10W, 5% 4720-473J 4
R210 47K, 0805, RMG, 1/10W, 5% 4720-473J 4
R212 100 OHM, 0805, RMG, 1/10W, 5% 4720-101J 4
R213 0.12 OHM, 1206, RMG, 1/4W, 5% 4725-R12J 3, 4
R214 0.12 OHM, 1206, RMG, 1/4W, 5% 4725-R12J 3, 4
R215 47K, 0805, RMG, 1/10W, 5% 4720-473J 4
R218 10 OHM, 0805, RMG, 1/10W, 5% 4720-100J 4
R219 10 OHM, 0805, RMG, 1/10W, 5% 4720-100J 4
R230 10 OHM, 0805, RMG, 1/10W, 1% 4720-100A 4
