Mount and dismount the Vivo 45 LS as shown in the picture:
1
2
The bottom plate is mounted to the trolley using two screws.
Be careful when handling the trolley with the ventilator mounted, in order to avoid any
risk of the trolley falling. The trolley can be tipped 10° and return to vertical position,
when loaded in accordance with the weight specifications below.
WARNING!
The maximum total weight of the trolley and added accessories is 37 kg (82 lbs).
(Trolley base weight = 12 kg (26 lbs), maximum externally added load = 25 kg (55
lbs).)
• The maximum load of the trolley basket is 0.9 kg (2 lbs).
• The maximum load of the IV-pole is 3 kg (6.5 lbs).
• The maximum load of the trolley rail is 9 kg (20 lbs).
• The maximum load of the E-cylinder holder is 7.9 kg (17.5 lbs).
No maintenance is required.
108 How to Use the Vivo 45 LS
User manual
Doc. 007301 K-1
