LOWER THREADING
B-36
a
If the thread becomes tangled under the
bobbin winder seat, press once to
stop the bobbin winding.
b
Cut the thread with scissors near the
pre-tension disk.
a Pre-tension disk
c
Push the bobbin winder switch to the right,
and then raise the bobbin at least 10 cm
(4 inches) from the shaft.
d
Cut the thread near the bobbin and hold the
thread end with your left hand. Unwind the
thread clockwise near the bobbin winder
seat with your right hand as shown below.
e
Wind the bobbin again.
Setting the Bobbin
Press → → →
in this order to display a video example of
the operation on the LCD (see page B-29). Follow
the steps explained below to complete the
operation.
a
Press .
• Make sure that the thread passes through
the pre-tension disk correctly (page B-33).
• Use a bobbin thread that has been correctly
wound. Otherwise, the needle may break or
the thread tension will be incorrect.
• The included bobbin was designed specifically
for this machine. If bobbins from other models
are used, the machine will not operate
correctly. Use only the included bobbin or
bobbins of the same type (part code: SA156,
(SFB: XA5539-151)).
* Actual size
a This model
b Other models
c 11.5 mm (approx. 7/16 inch)
• Before inserting or changing the bobbin, be
sure to press in the LCD, otherwise
injuries may occur if the “Start/Stop” button
or any other button is pressed and the machine
starts sewing.
To Next Page
