3-32
Confidential
■ Error code AF
CCD model
CIS model
Document Scanner home position sensor is not turned off.
■ Error code B0
FFC for scanner module is not connected correctly or failure of the document scanner unit.
* This error is indicated on the LCD in the maintenance mode.
Scanner Locked
Open the Document Cover and release Scanner lock lever. Press Stop
key.
Scan Unable
See Troubleshooting and routine maintenance chapter in User's
Guide.
<User Check>
• Check that the scanner lock lever is unlocked.
- CCD model
Step Cause Remedy
1
Home position sensor harness not
connected correctly
Reconnect the home position sensor
harness.
2 Drive PCB failure Replace the drive PCB.
3 Belt broken Replace the belt.
4 Home position sensor failure Replace the home position sensor.
5 Scanner motor failure Replace the scanner motor.
6 Main PCB failure Replace the main PCB ASSY.
- CIS model
Step Cause Remedy
1 FFC cable not connected correctly Reconnect the FFC cable.
2 Drive PCB failure Replace the drive PCB.
3 Document scanner unit failure Replace the document scanner unit.
4 Main PCB failure Replace the main PCB ASSY.
Scanner Error
Step Cause Remedy
1
Harness for scanner module not
connected correctly.
Reconnect the harness for the CCD unit
correctly. (CCD model)
Reconnect the harness for the document
scanner unit correctly. (CIS model)
2 Scanner harness broken Replace the FFC cable ASSY.
3 Main PCB failure Replace the main PCB ASSY.
To Next Page
