Brother MFC-8370DN Service Manual

5-6
Confidential
4. SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening
torque
N · m (kgf · cm)
CCD
model
CIS
model
FU harness cover 1 Taptite pan B M4x20 1 0.7±0.1 (7±1)
Fuser unit Taptite pan B M4x20 1 0.7±0.1 (7±1)
Process cover stopper Taptite cup B M4x10 1 0.5±0.1 (5±1)
Emblem cover Taptite cup B M3x10 2 0.5±0.1 (5±1)
Side cover L Taptite bind B M4x12 2 0.7±0.1 (7±1)
Shield cover ASSY
(FG harness)
Taptite cup S M3x6 SR 4 0.75±0.1 (7.5±1)
CCD
model
ADF FG harness Taptite cup S M3x6 1 0.7±0.05 (7±0.5)
Hinge base R Taptite cup B M3x10 2 0.8±0.1 (8±1)
Hinge ASSY L
Taptite cup B M3x10 2 0.5±0.1 (5±1)
Taptite cup S M3x12 1 0.7±0.1 (7±1)
ADF side cover F
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Taptite cup S M3x8 1 0.5±0.1 (5±1)
ADF side cover R
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
ADF chute ASSY Taptite cup B M3x10 5 0.5±0.1 (5±1)
SX Chute Taptite cup S M3x8 2 0.5±0.1 (5±1)
Exit chute cover ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
ADF motor
Screw, pan (S/P
washer) M3X6
2
0.7±0.1 (7±1)
Motor frame ASSY Taptite cup S M3x8 3 0.7±0.05 (7±0.5)
Switch back solenoid ASSY Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
PF solenoid ASSY Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
ADF relay PCB Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
Paper feed plate Taptite cup S M3x8 2 0.7±0.05 (7±0.5)
Paper feed chute ASSY Taptite cup S M3x8 2 0.7±0.05 (7±0.5)
Separation rubber Taptite B M3x6 1 0.4±0.05 (4±0.5)
Drive frame sub ASSY DX Taptite cup B M3x10 3 0.5±0.1 (5±1)
Front frame Taptite cup B M3x10 3 0.5±0.1 (5±1)
Upper main chute ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
Rear sensor cover Taptite cup B M3x10 2 0.5±0.1 (5±1)
LF spring Taptite cup B M3x10 2 0.5±0.1 (5±1)
CIS
model
FG harness Taptite cup S M3x6 SR 2 0.75±0.1 (7.5±1)
Shield cover ASSY Taptite cup S M3x6 SR 2 0.75±0.1 (7.5±1)
ADF FG harness Taptite cup S M3x6 1 0.7±0.05 (7±0.5)
ADF unit Taptite bind B M4x12 2 0.8±0.1 (8±1)
Hinge ASSY Taptite cup S M3x10 3 0.9±0.05 (9±0.5)
ADF gear cover Taptite cup B M3x10 1 0.5±0.1 (5±1)

Brother MFC-8370DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Input color depth	48 bit
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Product color	Grey, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Card reader integrated	-
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Scan
Power consumption (standby)	85 W
Power consumption (average operating)	680 W
Package weight	21100 g
Digital sender	No
Maximum duty cycle	- pages per month

Weight and Dimensions

Depth	443 mm
Width	390 mm
Height	442 mm
