Brother MFC-8370DN Service Manual

3-42
Confidential
4.3 Paper Jam
■ Paper jam in the paper tray and front cover
Step Cause Check Result Remedy
1
Dirt on edge
sensor
Is there paper powder in
the edge sensor?
Yes
Clean the edge sensor.
2
Registration front
actuator/edge
actuator catching
on some position
Does the registration front
actuator/edge actuator
move smoothly?
No
Re-assemble the
registration front actuator/
edge actuator.
3
Registration front
sensor PCB
(registration front
actuator/edge
actuator failure)
Does the registration front
sensor move smoothly?
(Check it following the
procedure described in
"4.10 Sensor Operational
Check (Function code
32)" in Chapter 7)
No
Replace the registration
front sensor PCB ASSY.
4
Registration
solenoid failure
Is the problem solved
after replacing the
registration solenoid?
Yes
Replace the registration
solenoid.
5
Toner LED PCB
failure
Is the problem solved
after replacing the toner
LED PCB ASSY?
Yes
Replace the toner LED
PCB ASSY.
6
High-voltage
power supply PCB
failure
Is the problem solved
after replacing the High-
voltage power supply
PCB ASSY?
Yes
Replace the High-voltage
power supply PCB ASSY.
7
Main PCB failure Is the problem solved
after replacing the Main
PCB ASSY?
Yes
Replace the Main PCB
ASSY.

Brother MFC-8370DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Input color depth	48 bit
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Product color	Grey, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Card reader integrated	-
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Scan
Power consumption (standby)	85 W
Power consumption (average operating)	680 W
Package weight	21100 g
Digital sender	No
Maximum duty cycle	- pages per month

Weight and Dimensions

Depth	443 mm
Width	390 mm
Height	442 mm
