Brother MFC-8370DN Service Manual

7-3
Confidential
3. USER-ACCESS TO THE MAINTENANCE MODE
Basically, the maintenance-mode functions listed on the previous page should be accessed
by service personnel only. However, you can allow end users to access some of these under
the guidance of service personnel (e.g., by telephone).
The user-accessible functions (codes 06, 09, 10, 11, 12, 25, 43, 45, 53, 54, 77, 80, 82, 87, 88
and 91) are shaded in the table given on the previous page. Function code 10 accesses the
firmware switches, each of which has eight selectors. You should not allow end users to
access all of those selectors, but you can allow them to access user-accessible selectors
which are shaded in the firmware switch tables in APPENDIX 1.
The service personnel should instruct end users to follow the procedure given below.
(1) Press the [Menu], [Start], [Menu], and [ ] buttons in this order.
The "MAINTENANCE 10" appears on the LCD.
(2) Press the [ ] button or [ ] button several times to display the desired maintenance
code on the LCD.
Then press the [OK] button.
(3) To switch the machine back to the standby state, press the [Stop/Exit] button. When
each of the user-accessible functions is completed, the machine automatically returns to
the standby state.

Brother MFC-8370DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Input color depth	48 bit
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Product color	Grey, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Card reader integrated	-
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Scan
Power consumption (standby)	85 W
Power consumption (average operating)	680 W
Package weight	21100 g
Digital sender	No
Maximum duty cycle	- pages per month

Weight and Dimensions

Depth	443 mm
Width	390 mm
Height	442 mm
