FIRMWARE SWITCHES (WSW)
This appendix describes the functions of the Worker switches, which can be divided into two
groups: one is for customizing preferences designed for the shipping destination (Refer to
"4.18 EEPROM Customizing (Function code 74)" in Chapter 7) and the other is for modifying
preferences that match the machine to the environmental conditions. Use the latter group if
the machine malfunctions due to mismatching.
Each switch has eight selectors. However, some of them cannot be set by an end user. Only
selectors in the worker switch setting tables of this Appendix that are shaded can be set by
an end user.
The worker switch setting procedure is described in "4.6.1 Firmware switch setting (Function
code 10)" in Chapter 7.
■ Worker Switch
WSW No. Function Refer to:
WSW01 Dial pulse setting App. 1-4
WSW02 Tone signal setting App. 1-6
WSW03 PABX mode setting App. 1-7
WSW04 Transfer facility setting App. 1-9
WSW05 1st dial tone and busy tone detection App. 1-10
WSW06 [Redial/Pause] button setting and 2nd dial tone detection App. 1-11
WSW07 Dial tone setting 1 App. 1-13
WSW08 Dial tone setting 2 App. 1-14
WSW09 Protocol definition 1 App. 1-15
WSW10 Protocol definition 2 App. 1-16
WSW11 Busy tone setting App. 1-17
WSW12 Signal detection condition setting App. 1-18
WSW13 Modem setting App. 1-19
WSW14 AUTO ANS facility setting App. 1-20
WSW15 Redial facility setting App. 1-21
WSW16 Function setting 1 App. 1-22
WSW17 Function setting 2 App. 1-22
WSW18 Function setting 3 App. 1-23
WSW19 Transmission speed setting App. 1-24
WSW20 Overseas communications mode setting App. 1-25
WSW21 TAD setting 1 App. 1-26
WSW22 ECM and call waiting caller ID App. 1-26
WSW23 Communications setting App. 1-27
WSW24 TAD setting 2 App. 1-28
WSW25 TAD setting 3 App. 1-28
WSW26 Function setting 4 App. 1-29
WSW27 Function setting 5 App. 1-30
WSW28 Function setting 6 App. 1-31
WSW29 Function setting 7 App. 1-32
