Canon ImageCLASS MF4570dw User Manual

6-16
Using the Fax Functions
1 Press [ ] (Menu).
2 Press [ ] or [ ] to select <System Management
Settings>, and then press [OK].
Menu
Fax TX Settings
Fax RX Settings
Adjustment/Maintena...
System Management Se
When the system manager PIN is specified
Enter the system manager PIN.
“Text Input Method” (→P.1-9)
When you finished entering, press [ ] or [ ] to select <Apply>,
and then press [OK].
System Manager PIN
*******
<Apply>
1 2 3 4 5 6 7 8 9 0
<BS>
3 Press [ ] or [ ] to select <Communication
Management Settings>, and then press [OK].
System Settings
System Manager Info ...
Device Information ...
Network Settings
Communication Manage
4 Press [ ] or [ ] to select <Memory Lock
Settings>, and then press [OK].
If <Memory Lock PIN> is specified, use the numeric keys to enter it,
and then press [OK].
Communication Mgt. Set
Fax Settings
Memory Lock Settings
5 Press [ ] or [ ] to select <Off>, and then press
[OK].
Memory Lock Settings
Off
On
Fax documents saved in the memory are printed.
6 Press [ ] (Menu) to close the menu
screen.
Checking and Deleting Received Fax
Documents
You can check detailed information about fax documents
saved in memory. Also, you can delete unnecessary
documents.
NOTE
Stored documents in memory
You can specify the destination to forward the documents.
“Forwarding Received Fax Documents in Memory to Other
Destinations (Manual Forwarding)” (→P.6-14)
You can print stored documents.
“Printing Received Fax Documents” (→P.6-15)
Keys to be used for this operation
OK
Status Monitor/Cancel
1 Press [ ] (Status Monitor/Cancel).
2 Press [ ] or [ ] to select <Fax Job Status/
History>, and then press [OK].
Status Monitor/Cancel
Device Status
Copy Job Status
Fax Job Status/Histo
Print Job Status
3 Press [ ] or [ ] to select <RX Job Status>, and
then press [OK].
Fax Job Status/History
TX Job Status
RX Job Status
Job History
4 Press [ ] or [ ] to select a job to be checked or
deleted, and then press [OK].
Fax RX Job Status
12:52AM Receiving
12:54AM Waiting:Print
The detailed information is displayed.
Details
<Delete>
<Forward>
Job Number: 5004
Status: Waiting to ...

Canon ImageCLASS MF4570dw Specifications

General

Dimensions (WxDxH)	391.16 x 421.6 x 370.8 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	No
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	16 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	13.5 s
Copy speed (black, normal quality, A4)	26 cpm
Scan drivers	TWAIN, WIA
Grayscale levels	256
Input color depth	24 bit
Maximum scan area	Legal (216 x 356) mm
Image formats supported	BMP, GIF, JPG, PNG, TIF
Maximum scan resolution	9600 x 9600 DPI
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax resolution (black)	203 x 391 DPI
Total input capacity	- sheets
Total output capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	-
Market positioning	Home & office
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, TKIP, WEP, WPA-AES, WPA-PSK, WPA2-PSK
Power consumption (PowerSave)	4 W
Power consumption (average operating)	1090 W
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
