No. Name Main Units Reference
SL2 Cassette Pickup Solenoid Main Drive Unit “Removing the Cassette Pickup Solenoid” on page
93
SL3 Duplex Reversal Solenoid - “Removing the Duplex Reversal Solenoid” on page
94
Heater / Thermo Switch / Thermistor / Switch
No. Name Main Units Reference
H1 Fixing Heater Fixing Unit -
TP1 Fixing Thermo Switch Fixing Unit -
TH1 Fixing Thermistor Fixing Unit -
SW1001 Power Switch - -
SW301 Door Switch - -
