■ Internal
J801
J802
J207
J251
J303
J33
J32
J34
J503
J531
J532
J581
J201
J1103
J1101
J1105
J1104
J2100
J1102
J No. Sym-
bol
Name Relay con-
nector
J No. Sym-
bol
Name
J201 - Engin Controller PCB J33 - Main Controller PCB
J251 - Engin Controller PCB J503 - Sleep Interface PCB
J581 - Engin Controller PCB J2100 - TAG
J207 - Engin Controller PCB J1102 - Power Supply PCB
J1101 - Power Supply PCB J1101 SL3 Duplex Reversal Solenoid
J1104 - Power Supply PCB J1104 SL2 Cassette Pickup Solenoid
J1105 - Power Supply PCB J1105 FM1 Main Fan
J1103 - Power Supply PCB J802 M2 Scanner Motor
J32 - Main Controller PCB J801 - Laser Driver PCB
J34 - Main Controller PCB J531 - Sleep Interface PCB
J303 - Main Controller PCB J532 - Sleep Interface PCB
