Canon XL H1A User Manual

104
Audio Output
Selecting the Audio Output of the RCA Terminals
Press the AUDIO MONITOR button.
Repeatedly pressing the button will cycle through the options in the following sequence: CH , CH and
CH / CH .
Selecting the Audio Channels
Open the menu and select [AUDIO SETUP]. Select [SEL AUDIO CH], select a setting
option and close the menu.
Selecting the Audio Mix
1. Open the menu and select [AUDIO SETUP]. Select [MIX SELECT], set it to [VARIABLE]
or [FIXED] and close the menu.
2. If you selected [VARIABLE], adjust the mix balance with the MIX BALANCE CH1/2 and
CH3/4 buttons on the wireless controller.
MENU
( 31)
AUDIO SETUP SEL AUDIO CH
•
CH / CH
MENU
( 31)
AUDIO SETUP MIX SELECT
•••
VARIABLE
AUDIO MONITOR button
AUDIO2 RCA terminals
AUDIO1 RCA terminals
SET button
MENU button
SELECT dial
1/2 3/4
1/2 3/4
1/3 2/4
