English
1. Speaker Setup [SPS]
The first item in the settings menu is the Speaker Setup. Here you can make sound-relevant settings relating to the connected speakers.
This Speaker Setup includes the menu items:
• Channel Level [CHL]
• Speaker Distance [DST]
• DRC [DRC]
• Voice Clarity [VOI]
• Speaker EQ [EQ ]
• Xover Small Speakers [XOV]
• Subwoofer Setup [SUB]
– Sub Phase [PHA] – Sub Stereo [SSM] – Sub Stereo Xover [SSX]
• Sound Setup [SND]
• Room Height [RHE]
• Device Height [DHE]
Channel Level [CHL]
At the Channel Level menu you can adjust the volume level of each individual channel in 1dB (1 Decibel) steps between -10dB and +10dB, where 0dB
is the factory setting. For an easier relative volume adjustment between the different speakers, the Soundbar 10 is equipped with a
test tone generator.
Caution: Before activating the test tone generator, please set the main volume to a level between 20 and 30. The test tone generator is depending
on the main volume level and cannot be increased or decreased within the menu.
For adjusting the relative volume of the different (virtual) speakers, please follow below instructions:
1
Press the menu button "M" on the remote to enter the menu.
2
Enter the first menu item Speaker Setup [SPS] by pressing the "OK" button.
3
Enter the menu Channel Level [CHL] by pressing the "OK" button.
4
As first item, Test Tone [TON] is selected automatically. Press the "OK" button if you want to activate the test tone generator.
5
Select [ON] to activate the test tone generator using the "+" button, select [OFF] to disable it using the "–" button.
6
Now, the front left [FL] speaker generates a pink noise signal. Press the "M" button and then the Down key " ", or directly the Down key " " to
select this left front [FL] speaker from the speaker list.
