Carel EVD evolution User Manual

31
ENG
“EVD evolution” +030222041 - rel. 1.0 - 01.06.2008
PARAMETERS TABLE8.
user*
Parameter/description Def. Min. Max. UOM
Type **
CAREL SVP
Modbus®
Notes
CONFIGURAZIONE
A Network address 198 1 207 - I 11 138
A Refrigerant:
R22 R134a R404A
R407C R410A R507A
R290 R600 R600a
R717 R744 R728
R1270 R417A R422D
R404A - - - I 13 140
A Valve:
CAREL E
X
V
Alco EX4
Alco EX5
Alco EX6
Alco EX7
Alco EX8 330Hz suggested by CAREL
Alco EX8 500Hz specified by Alco
Sporlan SEI 0.5-11
Sporlan SER 1.5-20
Sporlan SEI 30
Sporlan SEI 50
Sporlan SEH 100
Sporlan SEH 175
Danfoss ETS 25B
Danfoss ETS 50B
Danfoss ETS 100B
Danfoss ETS 250
Danfoss ETS 400
CAREL E
X
V - - - I 14 141
A Sensor S1:
Ratiometric (OUT=0 to 5 V) Electronic (OUT=4 to 20 mA)
-1 to 4.2 barg -0.5 to 7 barg
-0.4 to 9.2 barg 0 to 10 barg
-1 to 9.3 barg 0 to 18.2 bar
0 to 17.3 barg 0 to 25 barg
-0.4 to 34.2 barg 0 to 30 barg
0 to 34.5 barg 0 to 44.8 barg
0 to 45 barg remote, -0.5 to 7 barg
remote, 0 to 10 barg
remote, 0 to 18.2 barg
remote, 0 to 25 barg
remote, 0 to 30 barg
remote, 0 to 44.8 barg
External signal, 4 to 20 mA
Ratiometric:
-1 to 9.3 barg
- - - I 16 143
A Main control:
Multiplexed cabinet/cold room
Cabinet/cold room with on-board compressor
“Perturbed” cabinet/cold room
Cabinet/cold room with sub-critical CO
2
R404A condenser for sub-critical CO2
Air-conditioner/chiller with plate heat exchanger
Air-conditioner/chiller with tube bundle heat exchanger
Air-conditioner/chiller with finned coil heat exchanger
Air-conditioner/chiller with variable cooling capacity
“Perturbed” air-conditioner/chiller
EPR back-pressure
Hot gas bypass by pressure
Hot gas bypass by temperature
Transcritical CO2 gas cooler
Analogue positioner (4 to 20 mA)
Analogue positioner (0 to 10 V)
Analogue positioner (0 to 10 V)
Multiplexed
cabinet/cold
room
- - - I 15 142
A Sensor S2:
CAREL NTC CAREL NTC-HT high temp.
Combined NTC SPKP**T0 0 to 10 V external signal
CAREL NTC - - - I 17 144
A Auxiliary control:
Disabled
High condensing temperature protection on S3
Modulating thermostat on S4
Backup sensors on S3 & S4
Disabled - - - I 18 145
