TECHNICAL SPECIFICATIONS11.
Power supply
24 Vac (+10/-15%) 50/60 Hz to be protected by an external 2 A type T fuse. Use a dedicated class 2 transformer (max 100 VA).
Lmax=5 m.
Power input
30 VA
Emergency power supply
22 Vdc+/-5%. (If the optional EVBAT00200/300 module is installed), Lmax= 5 m
Insulation between relay output and
other outputs
reinforced; 6 mm in air, 8 mm on surface; 3750 V insulation
Motor connection
4-wire shielded cable AWG 18/22, Lmax 10 m
Digital input connection
Digital input to be activated from voltage-free contact or transistor to GND. Closing current 5 mA; Lmax= 30 m
Sensors (Lmax=10 m) S1 ratiometric pressure sensor (0 to 5 V):
•resolution0.1%FS;
•measurementerror:2%FSmaximum;1%typical
electronic pressure sensor (4 to 20 mA):
•resolution0.5%FS;
•measurementerror:8%FSmaximum;7%typical
combined ratiometric pressure sensor (0 to 5 V):
•resolution0.1%FS;
•measurementerror:2%FSmaximum;1%typical
4 to 20 mA input (max 24 mA):
•resolution0.5%FS;
•measurementerror:8%FSmaximum;7%typical
S2 low temperature NTC:
•10kΩat25°C,-50T90°C;
•measurementerror:1°Cintherange-50T50°C;3°Cintherange+50T90°C
high temperature NTC:
•50kΩat25°C,-40T150°C;
•measurementerror:1.5°Cintherange-20T115°C,4°Cintherangeoutsideof-20T115°C
combined NTC:
•10kΩat25°C,-40T120°C;
•measurementerror:1°Cintherange-40T50°C;3°Cintherange+50T90°C
0 to 10 V input (max 12 V):
•resolution0.1%FS;
•measurementerror:9%FSmaximum;8%typical
S3 ratiometric pressure sensor (0 to 5 V):
•resolution0.1%FS;
•measurementerror:2%FSmaximum;1%typical
electronic pressure sensor (4 to 20 mA):
•resolution0.5%FS;
•measurementerror:8%FSmaximum;7%typical
electronic pressure sensor (4 to 20 mA) remote. Maximum number of controllers connected=5
combined ratiometric pressure sensor (0 to 5 V):
•resolution0.1%FS
•measurementerror:2%FSmaximum;1%typical
S4 low temperature NTC:
•10kΩat25°C,-50T105°C;
•measurementerror:1°Cintherange-50T50°C;3°Cintherange50T90°C
high temperature NTC:
•50kΩat25°C,-40T150°C;
•measurementerror:1.5°Cintherange-20T115°C4°Cintherangeoutsideof-20T115°C
combined NTC:
•10kΩat25°C,-40T120°C;
•measurementerror1°Cintherange-40T50°C;3°Cintherange+50T90°C
Relay output
normally open contact; 5 A, 250 Vac resistive load; 2 A, 250 Vac inductive load (PF=0 .4); Lmax=10 m
Power to active sensors (V
REF
)
programmable output: +5 Vdc+/-2% or 12 Vdc+/-10%
RS485 serial connection
Lmax=1000 m, shielded cable
tLAN connection
Lmax=30 m, shielded cable
pLAN connection
Lmax=500 m, shielded cable
Assembly
DIN rail
Connectors
plug-in, cable size 0.5 to 2.5 mm
2
(12 to 20 AWG)
Dimensions
LxHxW= 70x110x60
Operating conditions
-10T60°C; <90% rH non-condensing
Storage conditions
-20T70°C, humidity 90% rH non-condensing
Index of protector
IP20
Environmental pollution
2 (normal)
Resistance to heat and fire
Category D
Immunity against voltage surges
Category 1
Type of relay action
1C microswitching
Class of insulation
2
Software class and structure
A
Conformity Electrical safety: EN 60730-1, EN 61010-1
Electromagnetic compatibility: EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4; EN61000-3-2, EN55014-1,
EN55014-2, EN61000-3-3.
Tab. 11.a
