5-19

Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers

OL-32185-02

Chapter 5 Install and Upgrade Internal Modules and FRUs

Overview of the SSD Carrier Card NIM (NIM-SSD)

Step 3 To remove the SSD one at a time, pull the two tabs on the front of each SSD as shown in Figure 5-14.

Step 4 Rotate the SSD card slot cover up and place it over the SSDs.

Step 5 Tighten the captive fasteners on the SSD card slot cover.

Figure 5-14 Pulling Out the Solid State Drives

347344

1 Carrier card slot cover

Default Chapter3
