4-32
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Security Configuration Menu
CTL File Menu
The CTL File screen includes the options that are described in Table 4-20.
If a CTL file is installed on the phone, you can access the CTL File menu by pressing the Settings button
and choosing Security Configuration > CTL File.
802.1X
Authentication
Allows you to enable 802.1X authentication
for this phone.
See the “802.1X Authentication and Status” section
on page 4-35.
802.1X
Authentication Status
Displays real-time status progress of the
802.1X authentication transaction.
Display only—Cannot configure.
Table 4-19 Security Menu Settings (continued)
Option Description To Change
Ta b l e 4-20 CTL File Settings
Option Description To Change
CTL File Displays the MD5 hash of the certificate trust list
(CTL) file that is installed in the phone. If security is
configured for the phone, the CTL file installs
automatically when the phone reboots or resets.
• A locked padlock icon in this option
indicates that the CTL file is locked.
• An unlocked padlock icon indicates that the
CTL file is unlocked.
For more information about the CTL file, refer
to the “Configuring the Cisco CTL Client”
section in Cisco Unified
Communications
Manager Security Guide.
CAPF Server Common Name (from the Cisco Unified
Communications Manager Certificate) of the CAPF
server used by the phone. Also displays a certificate
icon if a certificate is installed for this server.
For more information about this server, refer to
the “Using the Certificate Authority Proxy
Function” section in Cisco
Unified
Communications Manager Security
Guide.
