Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
• Expansion Module(s)—Displays the Expansion Module(s) screen, which shows information about
the Cisco
Unified IP Phone Expansion Module, if connected to the phone. For more information,
see the
“Expansion Module(s) Screen (SCCP Phones Only)” section on page 7-9.
To display the Status menu, press the Settings button and then select Status.
To exit the Status menu, press the Exit softkey.
Status Messages Screen
The Status Messages screen displays the 10 most recent status messages that the phone has generated.
You can access this screen at any time, even if the phone has not finished starting up.
Table 7-2 describes
the status messages that might appear. This table also includes actions you can take to address errors.
To display the Status Messages screen, follow these steps:
Procedure
Step 1 Press the Settings button.
Step 2 Select Status.
Step 3 Select Status Messages.
To remove current status messages, press the Clear softkey.
To exit the Status Messages screen, press the Exit softkey.
Ta b l e 7-2 Status Messages on the Cisco Unified IP Phone 7965G and 7945G
Message Description Possible Explanation and Action
BootP server used The phone obtained its IP address from a
BootP server rather than a DHCP server.
None. This message is informational only.
CFG file not found The name-based and default
configuration file was not found on the
TFTP Server.
The configuration file for a phone is created when the
phone is added to the Cisco
Unified Communications
Manager database. If the phone has not been added to the
Cisco
Unified Communications Manager database, the
TFTP server generates a
CFG File Not Found response.
• Phone is not registered with
Cisco
Unified Communications Manager.
You must manually add the phone to
Cisco
Unified Communications Manager if you are not
allowing phones to auto-register. See the
“Adding
Phones with Cisco Unified Communications Manager
Administration” section on page 2-11 for details.
• If you are using DHCP, verify that the DHCP server is
pointing to the correct TFTP server.
• If you are using static IP addresses, check
configuration of the TFTP server. See the
“Network
Configuration Menu” section on page 4-5 for details on
assigning a TFTP server.
