Cisco 7945G Administration Guide

D-1
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
APPENDIX
D
Technical Specifications
The following sections describe the technical specifications for the Cisco Unified IP Phone 7965G and
7945G.
• Physical and Operating Environment Specifications, page D-1
• Cable Specifications, page D-2
• Network and Access Port Pinouts, page D-2
Physical and Operating Environment Specifications
Table D-1 shows the physical and operating environment specifications for the Cisco Unified IP Phone.
Ta b l e D-1 Physical and Operating Specifications
Specification Value or Range
Operating temperature 32° to 104°F (0° to 40°C)
Operating relative humidity 10% to 95% (non-condensing)
Storage temperature 14° to 140°F (–10° to 60°C)
Height 9.07 in. (23.03 cm)
Width 10.82 in. (27.48 cm)
Depth • 2.54 in. (6.45 cm)—with footstand fully closed
• 6.0 in. (15.24 cm)—with footstand fully open
• 3.54 in. (9.00 cm)—with optional wall mount kit
Weight 3.25 lb (1.47 kg)
Power • 100-240 VAC, 50-60 Hz, 0.5 A—when using the AC adapter
• 44V-57V DC, 0.25 A—when using the in-line power over the
network cable

Cisco 7945G Specifications

General

Brand	Cisco
Model	7945G
Category	IP Phone
Language	English
