Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
Firmware Versions Screen
The Firmware Versions screen displays information about the firmware version that is running on the
phone.
Table 7-4 explains the information that is displayed on this screen.
To display the Firmware Version screen, follow these steps:
Procedure
Step 1 Press the Settings button.
Step 2 Select Status.
Step 3 Select Firmware Versions.
To exit the Firmware Version screen, press the Exit softkey.
Expansion Module(s) Screen (SCCP Phones Only)
The Expansion Module(s) screen displays information about each Cisco Unified IP Phone Expansion
Module that is connected to the phone. This screen appears on SCCP phones only.
Table 7-5 explains the information that is displayed on this screen for each connected expansion module.
You can use this information to troubleshoot the expansion module, if necessary. In the Expansion
Module(s) screen, a statistic preceded by “A” is for the first expansion module. A statistic preceded by
“B” is for the second expansion module.
To display the Expansion Module(s) screen, follow these steps:
Port 2 Link state and connection of the Network port
DHCP BOUND Phone is bound to the DHCP server, DHCP parameters are
acceptable, and the phone has received a DHCPACK message.
Table 7-3 Network Statistics Message Components (continued)
Item Description
Ta b l e 7-4 Firmware Version Information
Item Description
Load File Load file running on the phone
App Load ID Identifies the JAR file running on the phone
JVM Load ID Identifies the Java Virtual Machine (JVM) running on the phone
OS Load ID Identifies the operating system running on the phone
Boot Load ID Identifies the factory-installed load running on the phone
Expansion Module 1
Expansion Module 2
Identifies the load running on the Expansion Module(s).
DSP Load ID Identifies the digital signal processor (DSP) software version used
