Cisco 7945G Administration Guide

4-5
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
Related Topics
• Displaying a Configuration Menu, page 4-2
• Unlocking and Locking Options, page 4-3
• Editing Values, page 4-3
• Network Configuration Menu, page 4-5
• Device Configuration Menu, page 4-11
Network Configuration Menu
The Network Configuration menu provides options for viewing and making a variety of network settings.
Table 4-2 and Table 4-3 describe these options and, where applicable, explains how to change them.
For information about how to access the Network Configuration menu, see the “Displaying a
Configuration Menu” section on page 4-2.
Note The phone also has a Network Configuration menu that you access directly from the Settings menu. For
information about the options on that menu, see the “Network Configuration” section on page 4-27.
Before you can change an option on this menu, you must unlock options as described in the “Unlocking
and Locking Options” section on page 4-3. The Edit, Ye s , or No softkeys for changing network
configuration options appear only if options are unlocked.
For information about the keys you can use to edit options, see the “Editing Values” section on page 4-3.
TFTP settings If you do not use DHCP to direct the phone to a TFTP server, you must
manually assign a TFTP server. You can also assign an alternative
TFTP server to use instead of the one assigned by DHCP.
TFTP Server 1
Alternate TFTP
TFTP Server 2
Table 4-1 Settings Configurable from the Phone (continued)
Category Description
Network Configuration Menu
Option
Ta b l e 4-2 Network Configuration Menu Options
Option Description To Change
IPv4 Configuration In the IPv4 Configuration menu, you can do the following:
Enable or disable the phone to use the IP address that is assign by
the DHCP server.
Manually set the IP Address, Subnet Mask, Default Routers, DNS
Server, and Alternate TFTP servers.
For more information on the IPv4 address fields, refer to
Table 4-3.
1. Unlock network configuration
options.
2. Scroll to IPv4 Configuration
and press the Select softkey.
IPv6 Configuration This menu setting is disabled in this release.
MAC Address Unique Media Access Control (MAC) address of the phone. Display only—Cannot configure.
Host Name Unique host name that the DHCP server assigned to the phone. Display only—Cannot configure.
