Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Configuration
SW Port Configuration Speed and duplex of the switch port, where:
• A—Auto Negotiate
• 10H—10-BaseT/half duplex
• 10F—10-BaseT/full duplex
• 100H—100-BaseT/half duplex
• 100F—100-BaseT/full duplex
• 1000H—1000-BaseT/half duplex
• 1000F—1000-BaseT/full duplex
• No Link—No connection to the switch port
PC Port Configuration Speed and duplex of the switch port, where:
• A—Auto Negotiate
• 10H—10-BaseT/half duplex
• 10F—10-BaseT/full duplex
• 100H—100-BaseT/half duplex
• 100F—100-BaseT/full duplex
• 1000H—1000-BaseT/half duplex
• 1000F—1000-BaseT/full duplex
• No Link—No connection to the PC port
TFTP Server 2 Backup TFTP server that the phone uses if the primary TFTP server is
unavailable.
User Locale User locale associated with the phone user. Identifies a set of detailed
information to support users, including language, font, date and time
formatting, and alphanumeric keyboard text information.
Network Locale Network locale associated with the phone user. Identifies a set of detailed
information to support the phone in a specific location, including definitions
of the tones and cadences used by the phone.
Headset enabled Indicates whether the Headset button is enabled on the phone.
User Locale Version Version of the user locale loaded on the phone.
Network Locale
Ve r s i o n
Version of the network locale loaded on the phone.
PC Port Disabled Indicates whether the PC port on the phone is enabled or disabled.
Speaker Enabled Indicates whether the speakerphone is enabled on the phone.
GARP Enabled Indicates whether the phone learns MAC addresses from Gratuitous ARP
responses.
Video Capability
Enabled
Indicates whether the phone can participate in video calls when connected to
an appropriately equipped PC.
Voice VLAN Enabled Indicates whether the phone allows a device attached to the PC port to access
the Voice VLAN.
Table 8-2 Network Configuration Area Items (continued)
Item Description
