Cisco 7945G Administration Guide

8-9
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Statistics
To display a network statistics area, access the web page for the phone as described in the “Accessing
the Web Page for a Phone” section on page 8-2, and then click the Ethernet Information, the Access,
and or the Network hyperlink.
Ta b l e 8-3 Ethernet Information Area Items
Item Description
Tx Frames Total number of packets transmitted by the phone
Tx broadcast Total number of broadcast packets transmitted by the phone
Tx multicast Total number of multicast packets transmitted by the phone
Tx unicast Total number of unicast packets transmitted by the phone
Rx Frames Total number of packets received by the phone
Rx broadcast Total number of broadcast packets received by the phone
Rx multicast Total number of multicast packets received by the phone
Rx unicast Total number of unicast packets received by the phone
RxPacketNoDes Total number of shed packets caused by no Direct Memory Access (DMA)
descriptor
Ta b l e 8-4 Access Area and Network Area Items
Item Description
Rx totalPkt Total number of packets received by the phone
Rx crcErr Total number of packets received with CRC failed
Rx alignErr Total number of packets received between 64 and 1522 bytes in length that
have a bad Frame Check Sequence (FCS)
Rx multicast Total number of multicast packets received by the phone
Rx broadcast Total number of broadcast packets received by the phone
Rx unicast Total number of unicast packets received by the phone
Rx shortErr Total number of FCS error packets or Align error packets received that are
less than 64 bytes in size
Rx shortGood Total number of good packets received that are less than 64 bytes size
Rx longGood Total number of good packets received that are greater than 1522 bytes in size
Rx longErr Total number of FCS error packets or Align error packets received that are
greater than 1522 bytes in size
Rx size64 Total number of packets received, including bad packets, that are between 0
and 64 bytes in size
Rx size65to127 Total number of packets received, including bad packets, that are between 65
and 127 bytes in size
Rx size128to255 Total number of packets received, including bad packets, that are between
128 and 255 bytes in size
Rx size256to511 Total number of packets received, including bad packets, that are between
256 and 511 bytes in size
