Cisco 8851 Administration Guide

DescriptionParameter
The IP address for an authentication realm other than
the proxy IP address. The default value is blank; the
proxy IP address is used as the authentication realm.
The parameter for extension 1 appears as follows in
the phone configuration file:
<Reversed_Auth_Realm_1_ ua=”na”>
</Reversed_Auth_Realm_1_>
Reversed Auth Realm
The parameter by which the user agent will identify
itself for this line. If this field is blank, the actual URI
used in the SIP signaling should be automatically
formed as:
sip:UserName@Domain
where UserName is the username given for this line
in the User ID, and Domain is the domain given for
this profile in the User Agent Domain. If the User
Agent Domain is an empty string, then the IP address
of the phone should be used for the domain.
If the URI field is not empty, but if a SIP or SIPS URI
contains no @ character, the actual URI used in the
SIP signaling should be automatically formed by
appending this parameter with an @ character
followed by the IP address of the device.
SIP URI
XSI Line Service
DescriptionParameter
Enter the name of the server; for example, .
xsi.iop1.broadworks.net
XSI Host Server uses http protocol by
default. To enable XSI over HTTPS, you
can specify https:// in the server.
Note
For example:
https://xsi.iop1.broadworks.net
You can also specify a port for the server.
For example:
https://xsi.iop1.broadworks.net:5061
If you don't specify a port. The default port for the
specified protocol is used.
Default: Blank
XSI Host Server
Cisco IP Phone 8800 Series Multiplatform Phones Administration Guide
330
Cisco IP Phone Troubleshooting
XSI Line Service
