Cisco ASR 900 Series Configuration Guide

•
AU-3 Mapping
◦
Mode E3
◦
Mode T3
For more information, refer Configuring Modes under AU-3 Mapping.
Configuring Path Threshold
To configure path threshold:
enable
configure terminal
controller MediaType 0/5/0
mode sdh
controller sdh 0/5/0
au-4 1
threshold b3-ber_sd 7
threshold b3-ber_sf 7
end
Path Loopback
Sets a loopback to test the SDH port.
• local — Loops the signal from Tx to Rx path. Sends alarm indication signal (AIS) to network.
• network — Loops the signal from Rx to Tx path.
Configuring Path Loopback
To configure path loopback:
enable
configure terminal
controller sdh 0/5/0
au-4 1
loopback [local | network]
end
To restore the system to its default condition, use the no form of the command.Note
Configuring Path BERT
For more information on BERT configuration, see Configuring BERT in SDH for SAToP, on page 96 section.
Verifying Path Parameters Configuration
Use show running-configuration command to verify path parameters configuration.
#show running-configuration
controller MediaType 0/5/
1-Port OC-192 or 8-Port Low Rate CEM Interface Module Configuration Guide, Cisco IOS XE Everest 16.7.x (Cisco
ASR 900 Series)
95
Configuring SDH on 1-Port OC-192/STM-64 or 8-Port OC-3/12/48/STM-1/-4/-16 Module
Path Loopback
