Cisco RV180W Administration Guide

Viewing the Cisco RV180/RV180W Status
Viewing Port Statistics
Cisco RV180/RV180W Administration Guide 171
8
The Port Triggering Status window provides information on the ports that have
been opened per the port triggering configuration rules. The ports are opened
dynamically whenever traffic that matches the port triggering rules flows through
them.
The Port Triggering Status page displays the following fields:
Click Refresh to refresh the current page and obtain the latest statistics.
Viewing Port Statistics
The Port Statistics page displays port statistics.
To view port statistics:
STEP 1 Choose Status > Port Statistics.
STEP 2 In the Poll Interval field, enter the auto-refresh time interval in seconds. The
default value is 10.
STEP 3 To start the display of port statistics, click Start.
This page displays the latest port statistics based on the value you enter in the
Poll Interval field. For example, if you enter a poll interval value of 5, the router
refreshes the information on this page every 5 seconds.
This table displays the data transfer statistics for the Dedicated WAN, LAN, and
WLAN ports, including the duration for which they were enabled.
LAN (Local Network)
IP Address
Displays the LAN IP address of the device which
caused the ports to be opened.
Open Ports Displays the ports that have been opened so that
traffic from WAN destined to the LAN IP address
can flow through the router.
Time Remaining
Seconds
This field displays the time for which the port will
remain open when there is no activity on that port.
The time is reset when there is activity on the port.
