Technical specifications
The EX90/EX60 units are delivered with a fully integrated
codec, display, camera, microphone and loudspeakers, and a
Touch controller with a detachable wide band handset.
*
TE6.0 is a CUCM-only release and does not support all non-CUCM
features from software versions TC 5.x and earlier. TC6.0 does
not support all CUCM features from software version TE6.0. Full
feature parity in TC software was introduced in TC6.1.
product compAtibiLity
• Fully compatible with standards-compliant telepresence and video
systems
softwAre compAtibiLity
EX90:
• Cisco TelePresence Software
Version TC3.1 or later, and
TE6.0
*
EX60:
• Cisco TelePresence Software
Version TC4.0 or later, and
TE6.0
*
components
• Fully integrated unit including codec, display, camera, microphone
and loudspeakers
• Cables including: VGA-to-DVI-I cable, DVI-D cable, 3.5 mm jack
audio cable, LAN cable, power adapter, and power cable
dispLAy
EX90:
• 24 in. LCD monitor
• Resolution: 1920 × 1200
(16:10)
• Contrast ratio: 1000:1
• Viewing angle: 160°
• Response time: 5 ms
• Brightness: 300 cd/m
2
• 5° - 15° tilt
EX60:
• 21.5 in. LCD monitor (with LED
backlight)
• Resolution: 1920 × 1080
(16:9)
• Contrast ratio: 1000:1
• Viewing angle: 170°
• Response time: 5 ms
• Brightness: 225 cd/m
2
cAmerA
• Cisco TelePresence PrecisionHD design
• Resolutions: 1080p30 and 720p60
• Auto focus
• Integrated privacy shutter
• Document camera mode
• Multicoated all-glass optics
• 1/3-in., 2.1 megapixel CMOS sensor
EX90:
• Horizontal field of view: 45°-65°
• Vertical field of view: 40°-27°
• Focus distance 0.3-infinity
• Optical, motorized zoom
EX60:
• Horizontal field of view: 50°
• Vertical field of view: 29°
• Focus distance 0.1-infinity
Audio system
• Two stereo front speakers
• Integrated full-range microphone
• One 3.5 mm line-in jack for PC or other audio source
• Two 3.5 mm jack for headset
• Wideband handset
• Bluetooth version 2.1 + EDR
Only EX90:
• Integrated subwoofer
• Support for Cisco TelePresence Table Microphone 20
• HDMI audio input/output
pc And second source Video input
EX90:
• DVI-I
• HDMI In
EX60:
• DVI-I
supported pc input resoLutions
EX90:
• SVGA (800 × 600) to
WUXGA (1920 × 1200)
EX60:
• SVGA (800 × 600) to
1080p (1920 × 1080)
user interfAce
Cisco TelePresence Touch 8 controller
• Eight-inch projected capacitive touch screen
• Resolution: 800 × 480
LAnguAge support
• Danish, Dutch, English, Finnish, French, German, Italian, Japanese,
Korean, Norwegian, Portuguese-Brazilian, Russian, Simplified
Chinese, Spanish, Swedish
power
• Autosensing power supply
• 100–240 VAC, 50/60 Hz
EX90:
• 150 W max
EX90 with Touch 8:
• In video call: 110 W
• In standby: 58 W
EX60:
• 75 W max
EX60 with Touch 8:
• In video call: 46 W
• In standby: 31 W
