ENGINE

EW 10 - All Types

CYLINDER HEAD (continued)

Engine : RFN

Identification of the cylinder head gasket

B1DP183D

Nominal

dimension

Repair dimension

2 – 4 – 54 – 5

R1 R2

1.10.8

Gasket thickness

(mm)

Supplier MEILLOR

Marking zone

"e"

Marking zone

"d"

1.4

Multilayer metallic gasket

Presentation2
