Fuse N° Rating Function
F1 15 A Rear screen wipe (Tourer)
F2 30 A Locking and deadlocking relay
F3 5 A Airbags
F4 10 A Automatic gearbox - additional heater unit (Diesel) - electrochrome rear view mirrors
F5 30 A Front window - sun roof - passenger door lighting - passenger rear view mirror adjustment
F6 30 A Rear window
F7 5 A Vanity mirror lighting - Glove box lighting - interior lamps - torch (Tourer)
F8 20 A
Radio - CD changer - Controls at the steering wheel - Display - Defl ation detection - Electric
boot ECU
F9 30 A Cigar-lighter - front 12 V socket
F10 15 A Alarm - Controls on the steering wheel, signalling and screen wipe controls
F11 15 A Low current anti-theft switch
F12 15 A
Driver’s electric seat - instrument panel - seat belt not fastened warning lamps -air conditioning
controls
F13 5 A Engine relay unit - Hydraulic suspension pump cut-off relay - airbag ECU supply
F14 15 A
Rain and brightness sensor - parking assistance - passenger’s electric seat - trailer relay
unit - HIFI amplifi er ECU - Hands-free kit - Lane Departure Warning System
F15 30 A Locking and deadlocking relay
F17 40 A Heated rear screen - exterior heated rear view mirrors
FSH SHUNT PARK SHUNT
