– AMF20/25, SW version 2.2, ©ComAp – September 2014 70
IL-NT-AMF-2.2-Reference Guide.pdf
CT Location [GenSet/Load]
GenSet: Current CT´s are physically placed on GenSet (typically before GCB).
Load: Current CT´s are physically placed on Load (typically between GCB and MCB).
Hint:
More details about this function is introduced in chapter CT Location.
Comms Settings
ControllerAddr (1 .. 32) [-]
Controller identification number. It is possible to set controller address different from the default value
(1) so that more IL controllers can be interconnected (via RS485) and accessed e.g. from Modbus
terminal.
Hint:
When opening connection to the controller it's address has to correspond with the setting in PC tool.
From LiteEdit it is only possible to connect to controllers with address 1.
COM1 Mode [DIRECT/MODEM/MODBUS/ECU LINK]
Communication protocol switch for the COM1 channel.
DIRECT: LiteEdit communication protocol via direct cable.
MODEM: LiteEdit communication protocol via modem.
MODBUS: Modbus protocol. See detailed description in InteliCommunication guide.
ECU LINK: Protocol for communication with Cummins engines via Modbus.
Hint:
For details on communication speed and other technical parameters please see chapter Technical
Data.
For detail description see chapter Modbus protocol. Since IL-NT version 1.3 controller supports
register oriented Modbus.
COM2 Mode [DIRECT/MODBUS/ECU LINK]
Communication protocol switch for the COM2 channel, if dual communication module is plugged in.
DIRECT: LiteEdit communication protocol via direct cable.
MODBUS: Modbus protocol. See detailed description in InteliCommunication guide.
ECU LINK: Protocol for communication with Cummins engines via Modbus.
Hint:
For details on communication speed and other technical parameters please see chapter Technical
Data.
For detail description see chapter Modbus protocol. Since IL-NT version 1.3 controller supports
register oriented Modbus.
Hint:
Modbus TCP protocol using IB-Lite communication module requires setting COM1 Mode = DIRECT
and COM2 Mode = MODBUS.
ModemIniString
If your modem needs some additional initialization AT commands (i.e. because of national telephony
network differences), it can be entered here. Otherwise leave this setpoint blank.
ModbusComSpeed [9600,19200, 38400, 57600]
If the Modbus mode is selected on COM1 or COM2 channels, the Modbus communication speed in
bps can be adjusted here.
