InteliLite
NT
– AMF20/25, SW version 2.2, ©ComAp – September 2014 89
IL-NT-AMF-2.2-Reference Guide.pdf
SMS Language [1/2]
Select 1 to receive a message in primary controller language or 2 for secondary one.
Alternate Cfg
Based on the value on BI Alt. Config is selected controller configuration 1 or configuration 2 (all related
setpoints are placed in Alternate Cfg group).
Hint:
Controller will react on change of binary input only while engine is stopped. On successful change of
input the new record in history ("Nominal1Active", "Nominal2Active") is added.
Hint:
If the configuration 1 will contain setting for 50Hz and configuration 2 for 60Hz it is possible to use this
feature for 50/60 Hz switch.
Nominal RPM 1..2 [RPM]
Nominal engine speed.
Step: 1RPM
Range: 100 – 4000 RPM
Nominal Freq 1..2 [Hz]
Nominal generator frequency (usually 50 or 60 Hz )
Step: 1Hz
Range: 45 – 65 Hz
NomVolts Ph-N 1..2 [V]
Nominal generator voltage (phase to neutral)
Step: 1V
Range: 80 – 20000 V
Hint:
Phase sequence check is not possible to evaluate under voltage 50V what causes that if measured
voltage 50V is within the allowed range, controller will not allow to close the GCB, even if relevant LED
diode on front panel of IL-NT lits.
NomVolts Ph-Ph1..2 [V]
Nominal generator voltage (phase to phase)
Step: 1V
Range: 138 – 35000 V
Nomin Current 1..2 [A]
It is current limit for generator *IDMT over current and short current protection and means maximal
continuous generator current. See Gener Protect: *Amps IDMT Del, Short Crct Sd setpoints.
Nominal Current can be different from generator rated current value.
Step: 1 A
Range: 1 - 10000 A
ConnectionType 1..2 [3Ph4Wire / 3Ph3Wire / Split Ph / Mono Ph]
Generator winding connection.
3Ph4Wire: STAR Connection, 3 phases and neutral - 4 wires,
Three phase “wye” measurement – 3PY, 3x CT‘s
3Ph3Wire: DELTA Connection, 3 Phase without neutral - 3 Wires,
Three phase “delta” measurement – 3PD, 3x CT‘s
Split Phase: DOUBLE DELTA Connection, Split Phase,
Single-phase measurement – 1PH, 1xCT
Mono Phase: MONOPHASE,
