– AMF20/25, SW version 2.2, ©ComAp – September 2014 139
IL-NT-AMF-2.2-Reference Guide.pdf
Technical Data
Inputs/Outputs overview
Model
BIN
BOUT
AI
AOUT
COM1
COM2
CAN
RPM
Gen.
Voltage
Mains
Voltage
Gen.
Current
IL-NT AMF20
7+8*
+8**
7+8*
+8**
3+
4*
8**
Y**
Y**
N
Y
Y
Y
Y
IL-NT AMF25
7+8*
+8**
7+8*
+8**
3+
4*
8**
Y**
Y**
Y
Y
Y
Y
Y
Note:
* With optional extension module
IGS-PTM or IG-IOM
** With optional plug-in module
Y – Available
N – Not available
Generator protections
ComAp gen-set controllers provide following range of generator protections.
For each protection adjustable limit and time delay are available.
Comparison table with ANSI codes:
ANSI
code
Protection
IL-NT
AMF20
IL-NT
AMF25
59
Overvoltage
•
•
27
Undervoltage
•
•
47
Voltage Asymmetry
•
•
81H
Overfrequency
•
•
81L
Underfrequency
•
•
50+51
Overcurrent
***
•
46
Current Unbalance
•
•
32
Overload
•
•
51N+64
Earth Fault
-
•
32R
Reverse Power
-
-
25
Synchronism Check
-
-
47
Phase Rotation
**
**
37
Undercurrent
-
-
55
Power Factor
-
-
71
Gas (Fuel) Level
•
•
Note:
-
Not available
•
Available
**
Fixed setting
***
Shortcurrent only
Language support
