Analog inputs
Not electrically separated
Number of inputs 3
Resolution 10 bits
Maximal resistance range 2500 
Resistance measurement tolerance  2 %  2  out of measured value
Speed pick-up input
Type of sensor magnetic pick-up (connection by shielded
cable is recommended)
Minimum input voltage 2 Vpk-pk (from 4 Hz to 4 kHz)
Maximum input voltage 50 Veff
Minimum measured frequency 4 Hz
Maximum measured frequency 10 kHz (min. input voltage 6Vpk-pk)
Frequency measurement tolerance 0,2 %
D+ Function
Max. D+ output current 250 mA
Guaranteed level for signal Charging OK 80% of supply voltage
*CAN bus interface
Not electrically separated
Maximal CAN bus length 200m
Speed 250kBd
Nominal impedance 120
Cable type twisted pair (shielded)
Following dynamic cable parameters are important especially for maximal 200 meters CAN bus length
and 32 iS-COM units connected:
Nominal Velocity of Propagation min. 75% (max. 4,4 ns/m)
Wire crosscut min.0,25 mm
2
Maximal attenuation (at 1 MHz) 2 dB / 100m
Recommended Industrial Automation & Process Control Cables:
BELDEN (see http://www.belden.com):
 3082A DeviceBus for Allen-Bradley DeviceNet
 3083A DeviceBus for Allen-Bradley DeviceNet
 3086A DeviceBus for Honeywell SDS
 3087A DeviceBus for Honeywell SDS
 3084A DeviceBus for Allen-Bradley DeviceNet
 3085A DeviceBus for Allen-Bradley DeviceNet
 3105A Paired EIA Industrial RS485 cable
LAPP CABLE (see http://www.lappcable.com)
 Unitronic BUS DeviceNet Trunk Cable
 Unitronic BUS DeviceNet Drop Cable
 Unitronic BUS CAN
 Unitronic-FD BUS P CAN UL/CSA

ComAp intelilite nt amf25 Specifications

General

Brand	ComAp
Model	intelilite nt amf25
Category	Controller
Language	English
