InteliLite
NT
– AMF20/25, SW version 2.2, ©ComAp – September 2014 143
IL-NT-AMF-2.2-Reference Guide.pdf
IL-NT RS232 interface (optional card)
Plugs into IL-NT controller COMMUNICATION MODULE port.
Maximal distance 10m
Maximum Speed Up to 57.6 kBd (DIRECT), 38.4kBd Analog
modem, 9.6 kBd digital modem, 57.6 kBd (MODBUS)
Recommend external converter:
ADVANTECH – ADAM 4520: RS232 to RS422/485 converter, DIN rail, automatic RS485 bus
supervision, no external data flow control signals, galvanic isolated.
Recommended internal converter:
ADVANTECH – PCL-745B or PCL745S : Dual port RS422/485 Interface card, automatic RS485 bus
supervision, no external data flow control signals, galvanic isolated
Hint:
For details on all IL-NT extension and communication modules see IL-NT, IC-NT-Accessory Modules
manual.
With SW version IL-NT 1.2 and older, the communication speeds are 19.2kBd (STD/DIRECT),
19.2kBd Analog modem, 9.6 kBd digital modem, 9.6kBd (MODBUS)
IL-NT RS232-485 interface (optional card)
Plugs into IL-NT controller COMMUNICATION MODULE port.
Maximal distance 10m (RS232), 1200m (RS485)
Maximum Speed Up to 57.6 kBd (DIRECT), 38.4kBd Analog
modem, 9.6 kBd digital modem, 57.6 kBd (MODBUS)
Hint:
This module is supported with SW version IL-NT 1.3 and newer.
IL-NT S-USB interface (optional card)
Plugs into IL-NT controller COMMUNICATION MODULE port.
Maximal distance 5m
Maximum Speed Up to 57.6 kBd (DIRECT), 38.4kBd Analog
modem, 9.6 kBd digital modem, 57.6 kBd (MODBUS)
Use only shielded A-B USB cables up to 5m length.
Recommend USB cable:
USB-LINK CABLE 1.8M – ComAp A-B USB cable.
Hint:
With SW version IL-NT 1.2 and older, the communication speeds are 19.2kBd (STD/DIRECT),
19.2kBd Analog modem, 9.6 kBd digital modem, 9.6kBd (MODBUS)
IL-NT AOUT8 interface (optional card)
Plugs into IL-NT controller EXTENSION MODULE port.
Number of PWM outputs 8
