Compac C4000 User Manual

C4000 Set-up
Set-up Modes
Compac Industries Ltd.
Page 22
www.compac.co.nz
'K'Factor Switch
Using the ‘K’ Factor Switch
Using the ‘K’ Factor Switch to Change a Setting
Step
ACTION
RESULT
1
Ensure that the nozzles are
hung up
Dispenser in idle state
2
Press and release the „K‟
Factor switch, in quick
succession, until the
desired setting is displayed.
The price display and volume
display indicates the desired
setting. See following
paragraphs.
3
Press and hold the „K‟ factor
switch.
A digit, of the displayed setting,
will begin to increment.
4
When the digit is correct,
release the „K‟ Factor
switch.
5
Repeat steps 3 and 4 for
each digit of the setting
The C4000 will
reset itself if the „K‟ factor
switch is left for more than 10
seconds.
Continue for multiple hose units, if appropriate.
6
Press and release the „K‟
factor switch 8 or more
times in quick succession
The setting for side “B” (or
hose 2, 3, or 4) is displayed.
7
Repeat steps 3 to 5 above.
The C4000 will reset at any stage during the 'K' Factor
operation if the switch is not pressed for ten (10) seconds. If the C4000
resets out of any field before the numbers have been set correctly, then that
field must be entered again to ensure the details are correct.
The K-Factor switch must be sealed with a lead or paper seal
after commissioning.
