Compac C4000 User Manual

Triacs C4000 LPG Single/Dual, CNG & Bulk Meter
Solid State Relays (Triacs)
Compac Industries Ltd.
Page 64
www.compac.co.nz
Triacs C4000 LPG Single/Dual, CNG & Bulk Meter
Power
Terminal
Function
High / Low
LPG Single/Dual
CNG
Bulk Meter
Current output
T1
Electric Motor Control (SW1 =
2) side „A‟
Low A (SW1 = 2)
Electric Motor Control (SW1 = 2)
Low (300 mA max)
T2
Secondary Coil Solenoid
Control Side „A‟
Spare
Low Flow. New Compac OCV
Control N/C Solenoid
Low (300 mA max)
T3
Primary Coil Solenoid Control
Side „A‟
Med 1A
High Flow. New Compac OCV
Control N/C Solenoid
Low (300 mA max)
T4
Electric Motor Control (SW2 =
mid) Side „B‟, looped to T1
High A (SW2 = 2)
Tank Valve Signal (SW2 = 2)
Low (300 mA max)
T5
Secondary Coil Solenoid
Control Side „B‟
Spare
Spare
Low (300 mA max)
T6
Primary Coil Solenoid Control
Side „B‟
Low B
Caltex
Low (300 mA max)
T7
Spare
Med 1B (SW4 = 2)
Mobil (SW4 = 2)
Low (300 mA max)
T8
Spare
Spare
Shell
Low (300 mA max)
T9
Spare
High B
BP
Low (300 mA max)
T10
Excess flow output - Turned on
if flow rate exceeds
100litres/min. Stays on until
dispenser turned off.
Auxiliary Output for
CNG Compressor
Control
Additive Pulse
Low (300 mA max)
