Display (Litres) Resolution
Display (Litres) Resolution
For standard dispenser/pumps, high flow dispenser/pumps & bulk metering,
different resolutions are often required:
Sr setting
on k factor
switch
Litres Display
resolution
Max
presetable or
fill amount
000000[0]
[0] is not
displayed
As well as displaying the decimal point, a full colon will show
on the display after 'power on', until the first transaction is started (i.e. the
display shows „:0.0‟ until the first new transaction begins).
The display resolution does not affect the price display, which will always
display to a resolution of 0.01 dollars.
Setting the Display Resolution
Refer to C4000 Set-Up K Factor Switch Settings (see page 21)
Ensure that the nozzles are
hung up
Press and release the „K‟
Factor switch continuously
until the Litres resolution is
displayed
The price display indicates „Sr‟
and the Litres Resolution is
displayed as “0.00” (standard
resolution on 5-digit display)
Press and hold the „K‟ factor
switch.
The decimal point will begin to
move.
When the resolution
(decimal point) is correct,
release the „K‟ Factor
switch.
The C4000 will
reset itself if the „K‟ factor
switch is left for more than 10
seconds.
To Next Page
