Compac C4000 User Manual

Solid State Relays (Triacs)
Triacs C4000 MPD6 & MPP6 side A
Compac Industries Ltd.
Page 63
www.compac.co.nz
Triacs C4000 MPD6 & MPP6 side A
Power
Terminal
Symbol
Function
High / Low
Current Output
MPD6 / MPP6 side 'A'
MPD6 / MPP6 side 'B'
T1
or
LOAD1
MTR1 /
MTR3
Motor 1 relay control (SW1 = 2)
or
Internal pump motor 1 (SW1 = 1)
Motor 3 relay control (SW1 =
(SW1 = 1)
Low 300mA max
High (40 A max)
T2
SFS1
Secondary Flow Coil
Solenoid 1
Secondary Flow Coil
Solenoid 1
Low (300 mA max)
T3
PFS1
Primary Flow Coil
Solenoid 1
Primary Flow Coil
Solenoid 1
Low (300 mA max)
T4
or
LOAD2
MTR2
Motor 2 relay control (SW2 = 2)
or
Internal pump motor 2 (SW2 = 1)
Motor 2 relay control (SW2 = Mid)
or Internal pump motor 2 (SW2 =
Mid)
Low 300mA max
High (40 A max)
T5
SFS2
Secondary Flow Coil
Solenoid 2
Secondary Flow Coil
Solenoid 2
Low (300 mA max)
T6
PFS2
Primary Flow Coil
Solenoid 2
Primary Flow Coil
Solenoid 2
Low (300 mA max)
T7
MTR3 /
MTR1
Motor 3 relay control (SW4 = 2)
or
Internal pump motor 3 (SW = Mid)
Motor 1 relay control (SW4 = Mid)
or Internal pump motor 1 (SW4 =
Mid)
Low 300mA max
High (40 A max)
T8
SFS3
Secondary Flow Coil
Solenoid 3
Secondary Flow Coil
Solenoid 3
Low (300 mA max)
T9
PFS3
Primary Flow Coil
Solenoid 3
Primary Flow Coil
Solenoid 3
Low (300 mA max)
T10
Spare
Spare
Low (300 mA max)
For a six hose MPD / MPP: T1 of side 'A' loops to T7 of side 'B', T4 of side 'A' loops to T4 of side 'B', and
T7 of side 'A' loops to T1 of side 'B'.
