D-Link DGS-1100 Series Switch User Manual
Figure 7-4 MAC Address Table Settings (MAC Address Learning) window
The fields that can be configured are described below:
Parameter Description
From Port / To Port
Select the range of ports that will be used for this
configuration here.
State
Select to enable or disable the MAC address learning
function on the ports specified here.
Click the Apply button to accept the changes made.
MAC Address Table
This window is used to view the entries listed in the MAC address table.
To view the following window, click L2 Features > FDB > MAC Address Table, as shown below:
Figure 7-5 MAC Address Table window
Click the Clear All button to clear all dynamic MAC addresses.
