D-Link DGS-1100 Series Switch User Manual
12. Green
Power Saving
EEE
Power Saving
This window is used to configure the power saving settings of the Switch.
To view the following window, click Green > Power Saving, as shown below:
Figure 12-1 Power Saving window
The fields that can be configured are described below:
Parameter Description
Link Detection Power
Saving
Select this option to enable or disable the link detection
state. When enabled, a port which has a link down status
will be turned off to save power to the Switch. This will not
affect the port’s capabilities when the port status is link up.
Scheduled Port-shutdown
Power Saving
Select this option to enable or disable applying the power
saving by scheduled port shutdown.
Scheduled Hibernation
Power Saving
Select this option to enable or disable applying the power
saving by scheduled hibernation power.
Scheduled Dim-LED Power
Saving
Select this option to enable or disable applying the power
saving by scheduled dimming LEDs.
Administrative Dim-LED
Select this option to enable or disable the port LED function.
Type
Select the type of power saving. Option to choose from is
Dim-LED or Hibernation.
Time Profile
If a Time Profile was previously created, select the desired
profile from the drop down list.
Click the Apply button to accept the changes made for each individual section.
Click the Delete button to remove the specified entry.
After clicking the Power Saving Shutdown Settings tab, the following page will appear.
