D-Link DGS-1100-18 User Manual

D-Link DGS-1100 Series Switch User Manual
Multicast Filtering
This window is used to view and configure the Layer 2 multicast filtering settings.
To view the following window, click L2 Features > L2 Multicast Control > Multicast Filtering, as
shown below:
Figure 7-292 Multicast Filtering window
The fields that can be configured are described below:
Parameter Description
Multicast Filter Mode
Select the multicast filter mode here. Options to choose from
are Forward Unregistered, and Filter Unregistered. When
selecting the Forward Unregistered option, registered
multicast packets will be forwarded based on the forwarding
table and all unregistered multicast packets will be flooded
based on the VLAN domain. When selecting the Filter
Unregistered option, registered packets will be forwarded
based on the forwarding table and all unregistered multicast
packets will be filtered.
Click the Apply button to accept the changes made.
